5V Power Supply Board for Gottlieb
System 80B & System 3
Replacement A2 Board for Gottlieb Premier Pinball Machines.


Upgrade your machine now!

5V Power Supply Board
Status: Limited Availibility
$65.00
See our ebay Store to order these and other products.

eBay Store: bostonpinballcompany
Free Shipping to US customers, outside US we will send a shipping quote after your order.
Also see our Ebay Store or Email us

Design Information

The installation of the new power supply board takes about 10 minutes.

New features and improvements:

5V ADJUSTABLE Power Supply, very important, the original power supply was adjustable with a pot, which over time can be unreliable, and if it fails, the power supply could actually go to a high voltage and damage other boards in your machine. Our power supply has fix resistors with switches to adjust the voltage, much more reliable and stable.
Our supply is adjustable from 5.0V to 5.6V, why is this important? Did you install a new 5V fixed voltage power supply and are still having CPU resests and funny machine behavior, could be that new non-adjustable power supply.
Older machines and even machines with new CPU and other boards with lots of LEDs can have the same problem. The problem is long wire runs, lots of connectors, and long paths of traces on the PCBs can have enough resistance to lower the voltage by the time it reaches all the 5V points in your machine, causing low voltage points that can cause CPU resets and chips to not function correctly.  You need to measure voltages at many points and boards in you machine to ensure you are getting 5V to all points, anything less can cause problems. So with our board, just flip a few switches if you have low voltage points, problem solved.

Very efficient Power Supply, completely new design.
Ground connection point, test points.
All new capacitors, capacitors are known to degrade over time.

Works on System 80B and System 3 Machines.

Put a new heart into your machine so it runs for many more years!!!

All new components, not 30 years old! Today's components are higher quality and more reliable. These new boards will last a lot longer than old reconditioned, retested, removed from old machines, or new old stock boards.

Extra ground wire connection, the old Gottlieb boards did not have a very good ground scheme, we have added the additional ground that is needed to connect to chassis ground. This provides additional protection and stability.

Used in the following 80B Gottlieb Pinball Machines:

Amazon Hunt 2, Arena, Diamond Lady, Genesis, Gold Wing, Hollywood Heat, Monte Carlo, Raven, Robo-War, Rock, Rock Encore, Spring Break, TX-Sector, Victory
Bad Girls, Big House, Bone Busters, Excalibur, Hot
Shots

Replaces Original Part Numbers MA645, MA831

Used in the following System 3 Gottlieb Pinball Machines:


Barb Wire, Bell Ringer, Bullseye, Cactus Jack's, Car Hop, Caribbean Cruise, Class of 1812, Cue Ball Wizard, Deadly Weapon, Frank Thomas' Big Hurt™, Freddy A Nightmare on Elm Street, Gladiators, Hoops, Lights...Camera...Action!, Mario Andretti, Nudge-It, Operation: Thunder, Rescue 911, Shaq Attaq, Silver Slugger, Stargate, Street Fighter II, Strikes 'N Spares, Super Mario Bros., Super Mario Bros. Mushroom World, Surf 'n Safari, Tee'd Off, Title Fight, Vegas, Waterworld, Wipe Out, World Challenge Soccer



Replaces original Part Numbers MA1359
